YET612 Multi-Angle Rotatable Reflective Infrared Photocell Sensor: A Preferred Detection Accessory for Security Protection

In security projects such as automatic door control, factory perimeter wall protection, garage parking, warehouse security, and balcony/window security, the YET612 blind-spot-free reflective infrared photoelectric sensor has become a commonly used detection device in engineering security projects due to its adjustable angle, long-distance detection, and wide voltage compatibility.

This sensor uses a 740nm visible red light emission design, and when paired with an imported reflector, it can achieve a maximum detection range of 13 meters, flexibly adapting to security deployments of both short and long distances.

The sensor body supports ±90° wide-range rotation adjustment, allowing for free adjustment of vertical and lateral angles. Even in installation environments with irregular walls or varying heights, it can be aligned with the reflector without changing the drilling position, significantly reducing on-site construction difficulty. It can be installed from the front or side.

With excellent power supply compatibility, it supports dual-voltage input of AC 9~24V and DC 12~30V, making it compatible with the power supplies of most access control, barrier gates, and security controllers on the market. The device boasts superior power consumption control, with a 12V operating current of less than 35mA and a 24V current as low as 19mA, ensuring energy-efficient and durable operation even under continuous 24-hour power supply. It exhibits strong environmental adaptability, operating stably from -20℃ to +60℃ and withstanding up to 5000Lux of strong light.

During use, simply avoid highly reflective materials such as mirrors, locations subject to severe vibration, ensure dust protection for the probe, and avoid extreme weather conditions such as heavy rain and dense fog for long-term stable operation.

Widely compatible with scenarios such as lifting doors, sliding automatic doors, factory perimeter security, warehouse anti-theft, parking lot anti-collision protection, and villa door and window protection, it is a reliable choice for outdoor infrared protection.
