Model No: CY-W102

Shenzhen Factory WiFi smart motion sensor Home Automation Battery power Alert sensor

This microwave sensor is used in automatic doors, garages, barriers, and indoor and outdoor security protection. The product uses ultra-low power consumption technology, and the battery life is more than 2 years. Designed for outdoor scene applications, it has the ability to resist rain erosion and at the same time has a good ability to resist sunlight interference to avoid product failures caused by sunlight interference.
Quantity :
Contact Now
black Microwave Sensor For Automatic Sliding Doors
Technical Data
product name:
Deper dl6 silver gray automatic sliding door microwave sensor

Overall dimension:
120MM (length) ×80MM (width) ×50MM (height)
Weight:
210 grams
Transmission frequency:
24.125GHz
Transmission power:
<20dBm EIRP
Emission frequency density:
<5MW/CM
Maximum mounting height:
3M
Minimum detection speed:
5CM/S (along the vertical axis of the sensor)
Power supply voltage:
12V~24VAC/DC+30%/-10%
Power supply frequency:
50~60Hz
Consumed power:
<2W (VA)
Maximum contact voltage:
42VAC~60VDC
Maximum contact current:
1A(resistance)
Maximum switching power:
30W (DC) /60VA(AC)
Holding time:
0.5 seconds
Temperature range:
-20℃~+55℃
Protection grade:
IP52
Housing color:
black,silver grey
