YET402WTR Two Channels Intelligent Receiver
YET402WTR-V2.0 (wireless intelligent 2-Channel receiver ) is a dual-system 433mhz AC/DC 9-24V universal controller integrating with RF 433mhz remote control and WIFI,the product interface output is two-way relays switch’s signal,which can achieve forward and reverse rotation of motor,and also achieve on and off conversion of the switch as well as control requirements of various special equipment.

YET402WTR-V2.0 can be mainly used in electric doors and windows, lifting equipment, gateways, barrier, elevators, industrial control,security industries and other fields.It is very universal is your daily using.
YET402WTR-V2.0 has some features , which make it very universal and intelligent.
1.Support Tuya App network connection.You can use your telephone to control your device;
2.Support 433.92mhz radio frequency communicationThis frequency can match many pieces device in our daily life;
3.Input voltage AC/DC 9-24V.The wide voltagemake it is more universal for all customers.
|
Working voltage |
AC/DC 9~24V |
|
Contact current: |
<3A |
|
Wlan Standard |
IEEE802.11b/g/n |
|
Working Frequency |
2.4G ~2.5G(2400M ~2483.5M)Hz/433Mhz |
|
Encryption type |
WEP/TKIP/AES |
|
Security regime |
WPA/WPA2 |
|
Receiving Sensitivity |
802.11 b: -91 dbm (11 Mbps) 802.11 g: -75 dbm (54 Mbps) 433 :-112 dbm |
|
Static current |
<100mA |
|
Working environment |
-40℃~ +80℃ 20% ~ 93% |
|
Storage environment |
-20℃~ +70℃ 20% ~ 93% |
|
Remote Control Capacity |
<30 |
|
Outputs mode |
Momentary\inter-locking\self-latching (Momentary mode working in a settable timing control) |
|
Decoder type |
1527/2262 |
|
Product dimension |
94*60*28.5mm |
